Professional Digital Effects Bluetooth Anti-noise Processor with PC Software and 4 Channel 7000W Power Amplifier MiCWL MX2 Kit
$170.00
Quality Assurance
Quality Assurance
· All products undergo strict quality inspections to ensure high-quality standards.
· We provide genuine products from original manufacturers, guaranteeing authentic and reliable sources.
After-Sales Service
After-Sales Service
· At least one year (or longer) product warranty covering faults and repairs.
· Dedicated after-sales service team to quickly respond to customer inquiries and repair needs.
Return and Exchange Policy
Return and Exchange Policy
· Flexible return and exchange policy, typically allowing applications within 7-30 days of receiving the product.
· Simple and convenient return and exchange process to ensure a good customer experience.
MiCWL Audio Inc.
Karaoke Professional Microphone Digital Effects Audio Processor Controller
Equipment
with USB to PC Software (Digital with) 24 Bit
2 / 3 Channel Mics input
Digital Power Amplifier for your choose
MSRP: $1499.00
Brand New - Original Packaging
Authorized Dealer - Warranty By Manufacturer of MICWL Audio Inc.
Professional-grade 24bit digital modulation, digital-to-analog conversion circuit, music, reverberation using DSP processing. The human voice is richer and clearer.
360 degree digital encoder controls the total music volume
Power-on reset function, users can set the volume status of music and microphone each time they turn on
Music, microphone, maximum output lock function
Each mode parameter has boot memory function
Intelligent subwoofer signal control processing (suitable for unmanned management operation of large and small karaoke rooms)
a Karaoke function
When the microphone switch is turned on and there is a signal input, the active bass output signal is automatically attenuated, and the attenuation volume is set by the individual
b disco function
As long as the microphone switch is turned off, the active bass output signal will instantly return to the set output value within 3 to 5 seconds.
For the use of karaoke private rooms, special DVD signal input is set as priority input, with the popular KOD/VOD computer song order system.
Computer RS232 multi-function control port, S terminal line remote control interface.
5 microphone inputs, 3 on the front panel, 2 on the rear panel
Subwoofer electronic crossover function.
6 channels of independent output, each channel is independently adjusted
Center and surround can output music and microphone at the same time, and the volume of music and microphone can be adjusted independently
The center and surround microphones can choose to have reverb and no reverb output
Anti-howling function F.B-EX
Shipment according to your choice
1.Bluetooth Anti-noise processor
2.Digital Digital with Software processor
3.Black Digital 2 / 4 Channel Power Amplifier (Old Design)
4.Digital 2 / 4 Channel Power Amplifier ( New Design)
4 Channel Power Amplifier: (PEAK 7000W)
5200 Watts @ 4 Ohms ( 1300W + 1300W + 1300W + 1300W)
2600 Watts @ 8 Ohms RMS ( 650W + 650W + 650W + 650W )
2 Channel Power Amplifier: (PEAK 6000W)
2600 Watts @ 4 Ohms ( 1300W + 1300W)
1300 Watts @ 8 Ohms RMS ( 650W + 650W )
1. MiCWL 6400 Digital Power Amplifier and other Commercial prodcuts integrated solutions for large shopping malls, conference hassls, transportation hubs and so on.
2. Use the world's most advanced efficient switching power supply (SMPS) and Class D power amplifier (CLASS D) design.
3. Patented design of high quality porous heat sink, in harsh environments can be normal in low temperature operation
4. adopts the imported teflon wire, ensure the transformer can normally work efficeently at high temperature.
5. Built in Digital audio processor function.
6. With volume switch,Adjustable volume
7. Full set of protection functions to ensure that the product normally working
8.With Combined signal function,Multiple amplifiers can be connected in parallel to drive multiple speakers.
PARAMETER:
Input Voltage: AC220~240V, 50/60Hz or AC110~120V, 50/60Hz
(please leave message or Choose)
XLR, Balanced Inputs
Speakon and 1/4" Outputs
Front-to-Rear Airflow and Cooling Fan
Technical Specification :
◆ Large capacity Digital Switching Power Amplifier
◆ Automatic limit output, short circuit, overload, over temperature, power-on delay and other protection functions
◆ The power amplifier is equipped with a delay start system to protect the speakers from impact and damage
◆ The rear panel is equipped with dual channels,
◆ Balanced input interface
◆ SPEAKON output connector
◆ 483MM standard frame structure
◆ The switching power supply of the power amplifier part has a separate cooling system
◆ The cooling fan is controlled by an advanced stepless variable speed circuit
◆ 1U design, light body, easy to carry and install
Output/Output (8Ω, 1kHz): 4x650W / 2x650W
Output/Output (4Ω, 1kHz): 4x1300W / 2x1300W
Distortion: <0.005%
S/N ratio: 112dB (A-weighting)
Damping coefficient: >1000
Conversion rate: 50V/us
Frequency Response/Frequency Response: 20Hz~20kHz +/-0.25dB
Total Distortion/Total Distortion: 1% (8Ω, at 600W)
Input Sensitivity/Input Sensitivity: +3dB * (0.775V)
Input Impedance: 10kΩ (electronically balanced/Balanced)
DC residual: <5mV
Connect terminal Connector:
Input (CH1-2 3-4): XLR input connector; Output (CH1-2 3-4): SPEAKON output; Power: AC power Input (CH1-2 3-4): XLR Input Connector; Output (CH1-2 3-4): SPEAKON Output; Power: AC power supply.
Indicator Lights:
Power indicator x 1 (green); input indicator x 2 (yellow); peak indicator x 2 (red); protection circuit action indicator x 1 (red) Power Indicator x 1 (Green), Input Indicator x 2 (Yellow ), Peak Indicator x 2(Red); Feedback Protect Indicator x 1(Red)
Power Supply Voltage:
AC220~240V, 50/60Hz / or AC110~120V, 50/60Hz (using internal jumper switch/Via inside jumping switch)
1/8 Rated Activity Consumed Power: 50W, 80W, 110W
Working Temperature Range: 0~50℃
Working Humidity Range:
Below 90%RH/Under 90% RH (But it can not be condensation)
How much Speaker can this amplifier drive:
It Can Drive 650W or less 650W @ 8 Ohm Sound Speaker each Channel
- If your speaker is no more than 650 watts, this amplifier is enough to drive.
( 4 Channel can Drive 4 Unit 650W Speakers )
Also have 800W small power / and 1400W Super power each Channel Digital Power Amplifier for Choice (please check our ebay store or contact us)
Warranty：
One Year Warranty Covered by MICWL Audio Inc.
